G-100 Clevis Self-Locking Hook

Name: G-100 Clevis Self-Locking Hook
Brand: Herc
SKU: x-026-07x
Price: 87.17 CAD
Availability: InStock

SKU: Part #x-026-07x

$87.17 CAD

Sale Low stock

Chain Size 1/4" to 5/16" 3/8" 1/2" 5/8" 3/4"

Quantity

View full details

Product Description

Hercules SLR X-026 series is a clevis self-locking hook is a specialized rigging component designed for chain. The combines a clevis-style attachment point with a safety mechanism that automatically closes and locks when a load is applied. This design is primarily used for chain slings in industrial lifting and towing to prevent accidental disengagement.

Material:
- Alloy Steel, Grade 100
- Finish: Powder Coated, Blue
- Identification: Trademark, Size/WLL

Specifications
- Standard: EN 1677-3 / ASTM A952/952M
- Design Factor: 4:1
- Identification: Trademark, Size/WLL,
Uses
- Material handling and load securement
- Designed to connect to " Grade 100 chain place chain size from the above

Key Feature
- Engineered for strength, safety, and durability
- Reliable performance under load
- Suitable for professional lifting and rigging applications
- Working Load Limit (WLL) see the above part numbers for working load
- The self-locking mechanism replaces traditional latch hooks, preventing accidental disengagement when the load is applied

Part Number	Grade 100 Chain Size (in)	Working Load Limit (lb)	Dimension A (in)	Dimension H (in)	Dimension K (in)	Dimension P (in)	Dimension T (in)	Weight Each (lb)
X-026-07	1/4-5/16	5,700	0.39	0.94	4.69	1.34	0.79	2.0
X-026-10	3/8	8,800	0.47	1.18	5.59	1.73	1.02	3.1
X-026-13	1/2	15,000	0.59	1.54	7.01	2.05	1.18	6.6
X-026-16	5/8	22,600	0.71	1.93	8.39	2.36	1.42	11.0
X-026-20	3/4	35,300	0.94	2.56	9.88	2.76	1.89	24.2
X-026-22	7/8	42,700	0.94	2.48	10.75	3.15	1.93	29.7

Product Type: X-026 Grade 100 Clevis Self-Locking Hook.

Material: Quenched and tempered alloy steel.

Compatible With: Grade 100 lifting chain in the sizes specified in the table.

Design Factor: 4:1.

Proof Load: Proof load tested to 2.5 times the Working Load Limit, with certification for each manufactured batch.

Fatigue Rating: Fatigue rated to 20,000 cycles at 1.5 times the Working Load Limit.

Compliance: Manufactured in accordance with EN 1677-3, ASME B30.26, ASME B30.10 and PAS 1061.

Reference Image:

X-026 Grade 100 Clevis Self-Locking Hook specification reference showing dimensions A, H, K, P and T

Specification	Value
Working Load Limit	6.7T, 6.7 Tons
Type	CLEVIS SELF LOCKING, Clevis Self-Locking
Size	1/2, 1/2“
Material	Forged Super Alloy Steel, Alloy Steel
Certification Standard	EN1677 / ASME B30.26
