Coffing JLC Electric Chain Hoist - 2 Ton Double Reeving 15 ft Lift 8 FPM 230/460 VAC

Product Description

The Coffing JLC Electric Chain Hoist is designed for dependable lifting, lowering and positioning in manufacturing, maintenance and industrial material-handling applications. These double-reeved models provide a 2 Ton lifting capacity with 10, 15 or 20 ft Lift configurations and one-speed operation.

Available models provide lifting speeds of 8 or 16 FPM and use a 1 hp hoist-duty motor. Electrical configurations include 115/230 VAC and 230/460 VAC options, depending on the selected model. Compact construction provides 20-13/16 in minimum headroom to help preserve available lifting space beneath the supporting structure.

A multiple-disc motor brake provides controlled stopping and dependable load holding. The durable load-chain system, enclosed gearing and industrial pushbutton controls support reliable performance during repetitive lifting applications. Applicable models include a NEMA 3R pushbutton control station for added protection in industrial environments.

Material:
Die-cast aluminum alloy housing
Heat-treated alloy steel gearing
Alloy steel load chain
Forged steel upper and lower hooks
White exterior finish

Compatible With:
Properly rated overhead suspension points
Coffing JLC hook and lug suspension configurations
Compatible Coffing plain, geared and motorized trolleys
115/230 VAC electrical systems for applicable models
230/460 VAC electrical systems for applicable models
Manufacturer-approved load chain and replacement components

Uses:
Manufacturing and production lifting
Assembly and fabrication operations
Equipment installation and maintenance
Warehouse material handling
Workstation load positioning
Repetitive lifting and lowering
Controlled positioning of machinery and components

Key Features:
2 Ton double-reeved construction
10, 15 and 20 ft Lift options
8 and 16 FPM lifting speeds
One-speed control
Multiple-disc motor brake
Compact 20-13/16 in headroom
1 hp hoist-duty motor
Available NEMA 3R pushbutton control
