L-320AN Eye Hooks - Weight Limit 1 Ton

Name: L-320AN Eye Hooks - Weight Limit 1 Ton
Brand: Crosby
SKU: 1022380
Price: 68.92 CAD
Availability: InStock

SKU: Part #1022380

$68.92 CAD

Sale Low stock

Working Load Limit 1 Ton 1.5 Ton 2 Ton 3 Ton 5 Ton 11 Ton 7 Ton 15 Ton 22 Ton

Quantity

View full details

Product Description

The Crosby L-320AN Alloy Eye Hooks are designed for heavy-duty overhead lifting and hoisting applications requiring superior strength, durability, and fatigue resistance. Manufactured from forged alloy steel and precision heat treated, these hooks provide reliable performance for industrial lifting, crane operations, offshore rigging, and demanding material handling applications.
The L-320AN series incorporates Crosby’s integrated latch system, low-profile hook tip, and QUIC-CHECK® inspection indicators to improve operational safety, inspection efficiency, and load engagement during lifting operations.

Material:
Forged alloy steel
Quenched and tempered construction
Integrated heavy-duty latch assembly

Specifications:
Available in alloy steel construction
Eye hooks are load rated and marked with Working Load Limit
Fatigue rated to 20,000 cycles at 1.5 times the Working Load Limit
Forged, quenched, and tempered for maximum strength and reduced weight
QUIC-CHECK® deformation and angle indicators forged into hook body
L-320AN models feature integrated S-4320 latch system
Low-profile hook tip improves rigging engagement
Heavy-duty latch interlocks with hook tip for added security
Alloy eye hooks 1t through 22t feature a 5:1 design factor
Alloy eye hooks 30t through 60t feature a 4.5:1 design factor
Can be proof tested to 2 times the Working Load Limit on applicable sizes
Meets ASME B30.10 requirements
Suitable for personnel hoisting applications when properly secured in accordance with OSHA requirements

Uses:
Heavy-duty overhead lifting
Crane and hoisting systems
Industrial rigging operations
Marine and offshore lifting
Construction and material handling

Key Features:
Forged alloy steel construction – Provides high strength with reduced weight
QUIC-CHECK® indicators – Allows fast visual inspection for deformation and misuse
Integrated latch system – Improves load retention and operational safety
Low-profile hook tip – Enhances load engagement and rigging efficiency
Fatigue resistant – Designed for repeated heavy lifting cycles
Proof tested – Engineered for demanding industrial lifting applications

Working Load Limit (tons)	Hook ID Code	Stock No.	Weight Each (lb)	Reach (in)	Overall Width (in)	Hook Body Width (in)	Hook Body Thickness (in)	Throat Opening (in)	Saddle Section Height (in)	Lower Body Width (in)	Eye Section Thickness (in)	Standard Latch Length (in)	PL-N Latch Length (in)	Inside Eye Diameter (in)	Standard Latch Reach (in)	PL-N Latch Reach (in)	Deformation Indicator Distance (in)	S-4320 Latch Kit Stock No.	SS-4055 Latch Kit Stock No.	PL Latch Kit Stock No.
1	D	1022380	0.61	3.34	2.86	1.26	0.73	0.93	0.63	0.63	0.36	0.87	—	0.75	0.85	—	1.50	1096325	—	—
1-1/2	F	1022391	0.89	3.79	3.15	1.38	0.84	0.97	0.71	0.71	0.42	0.91	—	0.91	0.96	—	2.00	1096374	—	—
2	G	1022402	1.44	4.24	3.55	1.50	1.00	1.00	0.88	0.88	0.50	0.91	—	1.13	1.02	—	2.00	1096421	—	—
3	H	1022413	2.07	4.84	3.99	1.62	1.13	1.19	0.94	0.94	0.56	1.09	—	1.29	1.14	—	2.00	1096468	—	—
5	I	1022424	4.30	5.91	4.88	2.00	1.44	1.53	1.46	1.33	0.72	1.37	1.00	1.56	1.41	1.50	2.50	1096515	—	1092000
7	J	1022435	8.30	7.51	6.26	2.50	1.81	1.75	1.66	1.53	0.91	1.61	1.31	2.03	1.93	1.88	3.00	1096562	—	1092001
11	K	1022446	15.00	9.16	8.54	3.00	2.25	2.41	1.88	1.63	1.11	2.21	1.81	2.44	2.32	2.25	4.00	1096609	—	1092002
15	L	1022457	20.77	10.19	8.39	3.26	2.59	2.62	2.19	1.94	1.27	2.31	2.00	2.84	2.42	2.31	4.00	1096657	—	1092003
22	N	1022468	39.50	12.82	10.30	4.26	3.00	3.41	2.69	2.38	1.57	3.18	2.75	3.50	2.78	2.56	5.00	1096704	—	1092004
30	O	1022477	60.00	14.07	13.63	5.00	3.66	4.00	3.00	3.00	1.75	3.73	—	3.50	3.51	—	6.50	—	1090161	1093716
37	P	1023565	105.00	18.19	14.07	5.38	4.63	4.17	4.00	3.19	2.00	3.97	—	4.50	3.92	—	7.00	—	1090189	1093717
45	S	1023583	148.00	20.13	15.44	6.00	5.12	4.54	4.50	3.53	2.19	3.95	—	4.94	4.77	—	8.00	—	1090189	1093718
60	T	1023609	228.00	23.73	18.51	7.00	6.06	5.42	5.50	3.91	2.53	5.26	—	5.69	5.72	—	10.00	—	1090205	1093719

Series: L-320AN Alloy Eye Hooks

Material: Forged alloy steel, quenched and tempered.

Finish: Self-colored / Crosby gold finish.

Design Factor: 5:1 for 1 ton through 22 ton models; 4.5:1 for 30 ton through 60 ton models.

Proof Load: 2.5 times the Working Load Limit for 1 ton through 22 ton alloy hooks; 2 times the Working Load Limit for 30 ton through 60 ton alloy hooks.

Performance: Fatigue rated to 20,000 cycles at 1.5 times the Working Load Limit.
