12 Ton Chain Hoist Test Stand - 119-1/4 in L x 39-1/2 in W

Product Description

Product Description:
This CM hoist test stand is a self-contained hydraulic testing system designed for static and dynamic testing of chain hoists and other compatible lifting equipment. It can apply test loads ranging from approximately 0.3 Ton, or 660 lb, to a maximum of 12 Ton, or 26,000 lb.

The stand uses a hydraulic cylinder and test frame to apply a controlled load to the suspended hoist. This arrangement allows service facilities to evaluate hoist operation, load holding, brake performance, and general function without handling separate test weights. The self-contained design also prevents the applied hydraulic test force from adding an additional test load to the supporting floor.

With overall dimensions of 119-1/4 in L x 39-1/2 in W, the test stand is suited to industrial hoist repair shops, inspection facilities, manufacturing plants, and maintenance departments. The complete stand weighs approximately 500 lb before the hoist being tested is installed.

Material:
Manufacturer frame material not specified
Hydraulic test system

Compatible With:
Chain hoists requiring test loads up to 12 Ton
Manual chain hoists
Lever-operated hoists
Compatible powered chain hoists

Uses:
Static load testing of hoists
Dynamic operating tests
Testing hoist brake performance
Post-repair functional verification
Periodic hoist inspection and maintenance
Industrial lifting-equipment service work

Key Features:
Self-contained hydraulic operation
Testing range from 660 to 26,000 lb
Supports static and dynamic testing
Eliminates the need for loose test weights
Approximately 500 lb stand weight
119-1/4 in L x 39-1/2 in W overall dimensions
