Coffing WR Series Electric Wire Rope Hoist - 2 Ton Single Reeving Large Frame 22 ft Lift 14 FPM

Product Description

Product Description:
The Coffing WR Series Electric Wire Rope Hoist is designed for heavy-duty powered lifting, lowering and load positioning in manufacturing, maintenance and industrial material-handling applications. These single-reeved large-frame models are available in 2 Ton, 3 Ton and 5 Ton capacities with lifting heights ranging from 20 to 35 ft.

The listed 2 Ton and 3 Ton configurations use 5/16 in wire rope, while the higher-capacity configurations shown use 3/8 in wire rope. Available lifting speeds range from 14 to 26 FPM, allowing the appropriate model to be selected for controlled positioning or faster production lifting.

The large-frame construction supports motors ranging from 2 to 5 hp, depending on the selected capacity and lifting speed. One-speed control and an AC disc-type braking system provide consistent operation, controlled stopping and dependable load holding during industrial service.

Material:
Steel wire rope
Metal hoist frame and housing
Machined metal rope drum
Hardened steel drive components
Forged steel hook assemblies

Compatible With:
Properly rated overhead suspension points
Approved fixed suspension systems
Compatible plain, geared and motorized trolleys
Electrical service matching the selected model
Manufacturer-approved wire rope and replacement components

Uses:
Heavy-duty industrial lifting
Manufacturing and production operations
Assembly and fabrication applications
Equipment installation and maintenance
Warehouse material handling
Repetitive lifting and lowering
Controlled positioning of machinery and components

Key Features:
2 Ton to 5 Ton capacity options
Single-reeved wire-rope construction
Large-frame industrial design
20, 22 and 35 ft Lift options
14, 16, 21 and 26 FPM lifting speeds
2 to 5 hp motor configurations
One-speed control
AC disc-type braking system
