Chester Swivel-Truck Precision-Bearing Manual Plain Trolley - 2 Ton, 3-5/8 to 5-1/2 in Beam Flange

Product Description

Chester swivel-truck precision-bearing manual plain trolleys provide manually controlled horizontal travel for compatible hoists and suspended loads operating on overhead runway beams. The listed configurations cover capacities from 1/4 to 6 Ton, with capacity-specific beam flange ranges, beam heights, wheel-tread diameters, and minimum curve radii. Their push-type operation is suitable for industrial lifting systems where powered or hand-geared trolley travel is unnecessary.

The swivel-truck arrangement allows the wheel assemblies to follow the runway alignment as the trolley moves, supporting travel through compatible curved beam sections. Precision-bearing wheel assemblies promote smooth rolling and help reduce the force required to position a properly supported load. Horizontal movement is produced by manually pushing or pulling the suspended hoist and load, eliminating the need for a trolley motor, electrical controls, compressed-air supply, or operating hand chain.

The 1/4 and 1/2 Ton models fit beam flanges from 2-5/8 to 4-5/8 in, accommodate a 4 in beam height, have a 9-7/8 in minimum-radius curve, and use a 3-5/8 in wheel-tread diameter. The 1 Ton model fits 3 to 4-5/8 in flanges with a 5 in beam height, 9-7/8 in minimum-radius curve, and 5 in wheel-tread diameter. The 1-1/2 and 2 Ton models fit 3-5/8 to 5-1/2 in flanges with a 6 in beam height, 19-1/2 in minimum-radius curve, and 6 in wheel-tread diameter. The 3 and 4 Ton models fit 4 to 7 in flanges with an 8 in beam height, 15-3/8 in minimum-radius curve, and 8 in wheel-tread diameter. The 5 and 6 Ton models fit 4-5/8 to 8 in flanges with a 10 in beam height, 33-7/8 in minimum-radius curve, and 9 in wheel-tread diameter.

Material:
Industrial metal trolley frame and side plates
Precision-bearing wheel assemblies
Trolley wheels and axles
Load-bearing suspension components
Beam-adjustment and fastening hardware
Exact manufacturer material grades not confirmed

Compatible With:
Hoists using a suspension connection compatible with the selected trolley
Overhead beams within the specified flange-width range
Beams matching the specified beam height
Straight or curved runway beams meeting the model-specific minimum-radius requirement
Capacity-matched suspension and mounting components

Uses:
Providing manual horizontal travel for suspended hoists
Positioning loads along overhead runway beams
Moving loads through compatible curved runway sections
Industrial maintenance and equipment installation
Fabrication and assembly operations
Production and manufacturing applications
Warehouse and general material handling

Key Features:
Manual push-type operation
Swivel-truck wheel arrangement
Precision-bearing wheel assemblies
Available in capacities from 1/4 to 6 Ton
Capacity-specific beam-flange compatibility
Model-specific beam-height requirements
Suitable for compatible straight and curved beams
Wheel-tread diameters from 3-5/8 to 9 in
No electric or pneumatic trolley power required
No separate trolley hand-chain drive
