LEVER HOIST 1-1/2 TON WITH 20 FEET OF LIFT TRACTEL BRAVO

Product Description

Product Description: The Tractel Bravo Lever Hoist is a 1-1/2 Ton capacity manual lever hoist designed for lifting, pulling, tensioning, and load positioning in industrial, construction, and rigging applications. Built to ASME B30.21 standards and finished in a durable blue powder coat, the Bravo series delivers reliable performance across a wide range of working environments. With a minimum headroom of 14.6 in and a 7 x 21 mm load chain, this hoist provides a balance of capacity and compact design suited for applications where overhead clearance is a consideration.

The Bravo lever hoist operates via a ratcheting lever mechanism that allows the operator to lift, lower, and hold loads with precise control using minimal effort. The free-chaining function enables rapid hook positioning without load engagement, reducing setup time during rigging operations. The 20 ft lift configuration provides extended vertical travel, making this model well suited for applications requiring greater hook travel such as elevated equipment installation, multi-level rigging, and maintenance operations in taller structures.

At 31.4 lb, the Bravo 1-1/2 Ton offers a practical combination of capacity and portability for field use across multiple work sites. As with all lever hoists, it should be used only within its rated capacity, inspected before each use, and operated in accordance with ASME B30.21 and applicable rigging regulations. This model does not include overload protection; operators must ensure loads do not exceed the rated working load limit.

Material: Steel Body and Load Hook Blue Powder Coat Finish 7 x 21 mm Load Chain

Compatible With: Standard Rigging Hardware Shackles and Hooks Beam Clamps and Trolleys

Uses: Vertical Lifting and Lowering Horizontal Pulling and Tensioning Load Positioning and Securing Equipment Installation and Maintenance Rigging and Construction Applications

Key Features: 1-1/2 Ton Capacity 20 ft Lift Height Chain Size: 7 x 21 mm Minimum Headroom: 14.6 in ASME B30.21 Certified Blue Powder Coat Finish Free-Chaining Function for Rapid Hook Positioning

Note: This model does not include overload protection. Do not exceed the rated working load limit. Inspect before each use and operate in accordance with ASME B30.21 and applicable rigging regulations.
