MANUAL HOIST 1/2 TON WITH 10 FEET OF LIFT TRALIFT

Product Description

Product Description: The Tractel Tralift Manual Chain Hoist is a 1/2 Ton capacity hand chain hoist designed for lifting and load positioning in industrial, construction, and rigging applications. Built to ASME B30.16 standards, the Tralift series is engineered for reliable performance in demanding environments where precise load control is required. With a 5 x 15 mm load chain, an 8 ft hand chain, and a minimum headroom of just 13.4 in, this hoist is well suited for overhead lifting operations in areas with restricted overhead clearance.

The Tralift operates via a hand chain drive mechanism that allows the operator to lift, lower, and hold loads with controlled, incremental movement. The robust gear train and load chain system deliver consistent performance across the full 1/2 Ton capacity range, while the compact body and low minimum headroom of 13.4 in make it one of the more headroom-efficient options in the Tralift line. The 10 ft lift height covers the majority of standard industrial and construction lifting tasks, and the hoist can be suspended from a fixed hook, beam clamp, trolley, or other compatible overhead structure.

At 18.7 lb, the Tralift 1/2 Ton 10 ft is the most portable configuration in the 1/2 Ton Tralift range, offering an excellent combination of capacity, compact size, and ease of transport and installation across multiple work sites. As with all chain hoists, it should be used only within its rated capacity, inspected before each use, and operated in accordance with ASME B30.16 and applicable rigging regulations. This model does not include overload protection; operators must ensure loads do not exceed the rated working load limit.

Material: Steel Body and Load Hook 5 x 15 mm Load Chain 8 ft Hand Chain

Compatible With: Beam Clamps Plain and Geared Trolleys Fixed Suspension Hooks Overhead Crane and Monorail Systems

Uses: Vertical Lifting and Lowering Load Positioning and Holding Industrial and Fabrication Shop Lifting Field Rigging and Construction Applications Equipment Installation and Maintenance

Key Features: 1/2 Ton Capacity 10 ft Lift Height Load Chain Size: 5 x 15 mm Hand Chain Length: 8 ft Minimum Headroom: 13.4 in ASME B30.16 Certified Suitable for Fixed Hook, Beam Clamp, or Trolley Suspension

Note: This model does not include overload protection. Do not exceed the rated working load limit. Inspect before each use and operate in accordance with ASME B30.16 and applicable rigging regulations.
