Tractel Hoist 1 Ton Chain Manual 20 6M Lift

Product Description

Product Description: The Tractel Tralift Manual Chain Hoist is a 1 Ton (2,000 lb / 1,000 kg) capacity hand chain hoist designed for lifting and load positioning in industrial, construction, and rigging applications. Built to ASME B30.16 standards, the Tralift series is engineered for reliable performance in demanding environments where precise load control and extended lift height are required. With a 6 x 18 mm load chain and a minimum headroom of 15.4 in, this hoist is well suited for overhead lifting operations requiring greater vertical travel in facilities, fabrication shops, and field rigging applications.

The Tralift operates via a hand chain drive mechanism that allows the operator to lift, lower, and hold loads with controlled, incremental movement. The robust gear train and load chain system deliver consistent performance across the full 1 Ton capacity range, while the compact body and low minimum headroom of 15.4 in make it suitable for installations with limited overhead clearance. The 20 ft lift height provides the extended reach needed for taller structures, mezzanines, and multi-level rigging operations, and the hoist can be suspended from a fixed hook, beam clamp, trolley, or other compatible overhead structure.

At 35.6 lb, the Tralift 1 Ton 20 ft is a practical and portable option for field use across multiple work sites where extended hook travel is required. As with all chain hoists, it should be used only within its rated capacity, inspected before each use, and operated in accordance with ASME B30.16 and applicable rigging regulations. This model does not include overload protection; operators must ensure loads do not exceed the rated working load limit.

Material: Steel Body and Load Hook 6 x 18 mm Load Chain

Compatible With: Beam Clamps Plain and Geared Trolleys Fixed Suspension Hooks Overhead Crane and Monorail Systems

Uses: Vertical Lifting and Lowering Load Positioning and Holding Industrial and Fabrication Shop Lifting Field Rigging and Construction Applications Equipment Installation and Maintenance

Key Features: 1 Ton (2,000 lb / 1,000 kg) Capacity 20 ft Lift Height Load Chain Size: 6 x 18 mm Minimum Headroom: 15.4 in ASME B30.16 Certified Suitable for Fixed Hook, Beam Clamp, or Trolley Suspension

Note: This model does not include overload protection. Do not exceed the rated working load limit. Inspect before each use and operate in accordance with ASME B30.16 and applicable rigging regulations.
