CLAMP 0 TO 2.13 VERTICAL WLL 12 TON

Part #:2701678
CLAMP 0 TO 2.13 VERTICAL WLL 12 TON

Please note: images may not be exact representations. Always refer to manufacturer's specifications.

CLAMP 0 TO 2.13 VERTICAL WLL 12 TON

Part #:2701678
$5,182.00
IP10 - 12t Vertical Lifting Clamp w/Straight Eye 0-2 1/8" Jaw • For vertical lifting, turning and transfer • Welded alloy steel body for strength and smaller size. Forged alloy components, where required. • Individually Proof Tested to 2 times the Working Load Limit with certification. • Company name (CrosbyIP), logo, Working Load Limit and jaw opening permanently stamped on body. • Each product is individually serialized, with the serial number and Proof Load test date stamped on body. User manual and test certificate included with each clamp . • IP10 - Standard clamp for materials with a surface hardness to 363HV10 (345 HB). • Full 180° turning range for material transfer, turning or moving. • Lock open, lock closed ability with latch for pretension on material and then release of material. • Maintenance and repair kits are available. • Minimum WLL is 10% of maximum WLL. • For plate surface hardness to 279HV10, only 5% minimum WLL is needed.

Description

IP10 - 12t Vertical Lifting Clamp w/Straight Eye 0-2 1/8" Jaw • For vertical lifting, turning and transfer • Welded alloy steel body for strength and smaller size. Forged alloy components, where required. • Individually Proof Tested to 2 times the Working Load Limit with certification. • Company name (CrosbyIP), logo, Working Load Limit and jaw opening permanently stamped on body. • Each product is individually serialized, with the serial number and Proof Load test date stamped on body. User manual and test certificate included with each clamp . • IP10 - Standard clamp for materials with a surface hardness to 363HV10 (345 HB). • Full 180° turning range for material transfer, turning or moving. • Lock open, lock closed ability with latch for pretension on material and then release of material. • Maintenance and repair kits are available. • Minimum WLL is 10% of maximum WLL. • For plate surface hardness to 279HV10, only 5% minimum WLL is needed.
