Budgit Spark-Resistant Manual Push Trolley - 1 Ton, 3 to 5 in Beam Flange

Product Description

Product Description:
Budgit spark-resistant manual push trolleys provide horizontal beam travel for compatible hoists and suspended loads. The listed configurations include a 1 Ton trolley designed for beam flange widths from 3 to 5 in and a 3/4 Ton trolley designed for beam flange widths from 4 to 6-1/4 in. Their manually propelled design is suitable for industrial lifting systems where powered or hand-geared trolley movement is unnecessary.

Horizontal travel is produced by pushing or pulling the suspended hoist and load along the supporting beam. This simple operating arrangement requires no electric traverse motor, pneumatic drive, pendant controls, or trolley hand chain. The trolley must be correctly matched to the hoist capacity, suspension connection, beam dimensions, flange profile, and required running clearance.

The spark-resistant configuration incorporates manufacturer-selected components intended to reduce the potential for mechanically generated sparks during trolley travel. These trolleys are suitable for maintenance, processing, fabrication, assembly, and material-handling applications where spark reduction is an important equipment-selection consideration.

Material:
Industrial metal trolley frame
Manufacturer-selected spark-resistant wheel and contact components
Metal suspension and load-bearing components
Beam-adjustment and fastening hardware

Compatible With:
Compatible Budgit hoists within the selected trolley’s rated capacity
Hoists with a suspension connection matching the trolley configuration
Overhead beams within the specified flange-width range
Runway systems providing the required wheel engagement and operating clearance

Uses:
Providing manual horizontal travel for suspended hoists
Positioning loads along overhead runway beams
Industrial maintenance and equipment installation
Fabrication and assembly operations
Processing and manufacturing applications
Material handling where reduced-sparking construction is required

Key Features:
Manual push-type operation
Spark-resistant configuration
Available in 3/4 and 1 Ton capacities
Model-specific beam-flange compatibility
No electrical or pneumatic trolley power required
No separate trolley hand-chain drive
Controlled horizontal movement along compatible beams
