Budgit Standard Geared Air Motor-Driven Trolley - 2 Ton, 60 FPM

Product Description

Budgit standard geared air motor-driven trolleys provide powered horizontal travel for compatible pneumatic hoists installed on overhead runway beams. The listed configurations include a combined 1/4, 1/2 and 1 Ton model operating at 50 FPM and separate 2 and 3 Ton models operating at 60 FPM. Pneumatic operation makes these trolleys suitable for production, maintenance and material-handling systems where compressed air is the preferred power source.

The air motor transfers power through the geared drive mechanism to move the trolley wheels along the supporting beam. Powered travel reduces the manual effort required to reposition suspended loads and provides more consistent movement than a push-type trolley. The system supports controlled forward and reverse travel for load positioning during equipment installation, fabrication, assembly and other industrial operations.

The 1/4, 1/2 and 1 Ton configuration fits beam flange widths from 3 to 5 in and can negotiate a 3 ft minimum-radius curve. The 2 Ton configuration fits beam flanges from 3-5/8 to 6-1/4 in, while the 3 Ton configuration fits beam flanges from 4 to 6-1/4 in. Both larger models require a 5 ft minimum-radius curve. All three configurations use a 4 in wheel-tread diameter and forged, heat-treated trolley wheels for durable beam travel.

Material:
Forged and heat-treated trolley wheels
Industrial metal trolley side frames
Steel suspension and beam-adjustment hardware
Pneumatic air motor
Metal gearing and drive components

Compatible With:
Compatible Budgit pneumatic chain hoists
Overhead beams within the selected trolley’s flange-width range
Straight or curved runway beams meeting the required minimum-radius specification
Compressed-air systems meeting the hoist and trolley operating requirements
Capacity-matched hoist suspension and trolley mounting components

Uses:
Providing powered horizontal travel for pneumatic hoists
Moving suspended loads along overhead runway beams
Positioning equipment during installation and maintenance
Production and assembly operations
Fabrication and manufacturing applications
Warehouse and industrial material handling
Applications where electric trolley power is unavailable or unsuitable

Key Features:
Available for 1/4 through 3 Ton loads
Pneumatic motor-driven travel
Standard geared-drive configuration
50 FPM travel on the 1/4 through 1 Ton model
60 FPM travel on the 2 and 3 Ton models
Adjustable beam-flange compatibility
4 in wheel-tread diameter
Forged heat-treated trolley wheels
Suitable for compatible straight and curved runway beams
Powered operation without an electric trolley motor
