Coffing CBTP Manual Plain Trolley - 1-1/2 Ton, 2.3 to 8.7 in Beam Flange

Product Description

Product Description:
Coffing CBTP manual plain trolleys are push-operated units designed to provide smooth horizontal movement of a hook-mounted hoist and suspended load along a compatible overhead beam. The 1-1/2 Ton model fits beam flanges from 2.3 to 8.7 in and beam heights from 6 to 24 in, with a 45 in minimum-radius curve and 3.15 in wheel tread diameter. The 1/4 Ton model fits beam flanges from 2 to 8.7 in and beam heights from 4 to 24 in, with a 27 in minimum-radius curve and 2.36 in wheel tread diameter.

Steel wraparound side plates provide a rugged trolley structure and incorporate protective lugs that add security while also acting as bumpers around the wheels. Dual-tread steel wheels allow the trolley to operate on compatible tapered or flat beam flanges, while lifetime-lubricated shielded ball bearings support smooth rolling with minimal routine maintenance.

The adjustable trolley assembly can be fitted to different beam widths within the specified range. A universal hanging clevis accepts most compatible hook-mounted manual or powered hoists, allowing the trolley to support industrial lifting systems used in maintenance, production, fabrication and material-handling environments. Horizontal movement is controlled by manually pushing or pulling the suspended load, eliminating the need for electrical power, a trolley motor or a separate hand-chain drive.

Material:
Steel wraparound side plates
Steel dual-tread wheels
Shielded ball bearings
Black enamel protective finish

Compatible With:
Hook-mounted manual hoists within the trolley’s rated capacity
Hook-mounted powered hoists within the trolley’s rated capacity
Compatible tapered-flange beams within the specified adjustment range
Compatible flat-flange beams within the specified adjustment range

Uses:
Providing manual horizontal travel for suspended hoists
Positioning loads along straight or curved overhead beams
Industrial maintenance and equipment installation
Fabrication and assembly operations
Warehouse and production material handling
Applications where powered trolley travel is unnecessary

Key Features:
Manual push-type operation
Universal hanging clevis
Adjustable beam-flange fit
Dual-tread wheels for tapered or flat flanges
Lifetime-lubricated shielded ball bearings
Wraparound side plates with protective lugs
Smooth rolling without external power
Designed for manual and powered hook-mounted hoists
