Name: Regular Eye Bolts
Brand: Herc
SKU: g2910402x
Price: 0.67 CAD
Availability: InStock

Product Description

HERC Regular Nut Eye Bolts are designed to provide secure attachment points for anchoring, tie-down, pulling, and general-purpose rigging applications. Supplied complete with a hex nut, these eye bolts are commonly used in industrial, marine, utility, agricultural, and construction environments where a permanent or semi-permanent attachment point is required. The simple eye pattern design provides an economical and versatile solution for a wide variety of non-critical attachment applications.

Manufactured from forged steel and protected with a hot-dip galvanized finish, HERC Regular Nut Eye Bolts provide dependable strength and corrosion resistance for indoor and outdoor service. Suitable for through-bolted installations, these eye bolts are commonly used for securing cables, ropes, chains, and anchoring systems in demanding environments.

Material:

Forged steel construction
Hot-dip galvanized finish

Uses:

Anchoring applications
Tie-down systems
Utility installations
Marine applications
Agricultural equipment
Construction projects
General rigging systems
Industrial attachment points

Key Features:

Regular eye bolt design – Provides a simple and versatile attachment point
Forged steel construction – Delivers dependable strength and durability
Hot-dip galvanized finish – Enhances corrosion resistance for outdoor use
Supplied with hex nut – Supports secure through-bolted installation
Available in multiple thread diameters and lengths
Suitable for anchoring and securement applications
Durable construction – Designed for long service life
Industrial-grade reliability

Important Operating Information:

Not intended for overhead lifting unless specifically rated and approved for lifting service.
Always verify the supporting structure is capable of supporting the applied load.

Part Number	Size (in)	Shank Diameter A (in)	Eye Inside Diameter B (in)	Eye Outside Diameter C (in)	Dimension D (in)	Thread Length E (in)	Shank Length F (in)	Overall Length G (in)	Dimension H (in)	Working Load Limit (lb)
G2911612X	1 x 12	1.00	2.00	4.00	1.00	4.00	12.00	16.31	2.31	13,300
G2911606X	1 x 6	1.00	2.00	4.00	1.00	3.00	6.00	10.31	2.31	13,300
G2911609X	1 x 9	1.00	2.00	4.00	1.00	4.00	9.00	13.31	2.31	13,300
G2910810X	1/2 x 10	0.50	1.00	2.00	0.50	3.00	10.00	12.12	1.12	2,600
G2910812X	1/2 x 12	0.50	1.00	2.00	0.50	3.00	12.00	14.12	1.12	2,600
G2910803-25X	1/2 x 3-1/4	0.50	1.00	2.00	0.50	1.50	3.25	5.38	1.12	2,600
G2910806X	1/2 x 6	0.50	1.00	2.00	0.50	3.00	6.00	8.12	1.12	2,600
G2910808X	1/2 x 8	0.50	1.00	2.00	0.50	3.00	8.00	10.12	1.12	2,600
G2910402X	1/4 x 2	0.25	0.50	1.00	0.25	1.50	2.00	3.06	0.56	650
G2911210X	3/4 x 10	0.75	1.50	3.00	0.75	3.00	10.00	13.19	1.69	7,200
G2911212X	3/4 x 12	0.75	1.50	3.00	0.75	4.00	12.00	15.19	1.69	7,200
G2911204-5X	3/4 x 4-1/2	0.75	1.50	3.00	0.75	2.00	4.50	7.69	1.69	7,200
G2911206X	3/4 x 6	0.75	1.50	3.00	0.75	3.00	6.00	9.19	1.69	7,200
G2911208X	3/4 x 8	0.75	1.50	3.00	0.75	3.00	8.00	11.19	1.69	7,200
G2910602-5X	3/8 x 2-1/2	0.38	0.75	1.50	0.38	1.50	2.50	4.12	0.88	1,550
G2910604-5X	3/8 x 4-1/2	0.38	0.75	1.50	0.38	2.50	4.50	6.12	0.88	1,550
G2910606X	3/8 x 6	0.38	0.75	1.50	0.38	2.50	6.00	7.62	0.88	1,550
G2910502-25X	5/16 x 2-1/4	0.31	0.62	1.25	0.31	1.50	2.25	3.56	0.69	1,200
G2910504-50X*	5/16 x 4-1/2	0.31	0.62	1.25	0.31	—	4.50	—	0.69	1,200
G2910504-25X	5/16 x 4-1/4	0.31	0.62	1.25	0.31	2.50	4.25	5.56	0.69	1,200
G2911010X	5/8 x 10	0.62	1.25	2.50	0.62	3.00	10.00	12.69	1.44	5,200
G2911012X	5/8 x 12	0.62	1.25	2.50	0.62	4.00	12.00	14.69	1.44	5,200
G2911015X†	5/8 x 15	0.62	1.25	2.50	0.62	5.00	15.00	17.69	1.44	5,200
G2911004X	5/8 x 4	0.62	1.25	2.50	0.62	2.00	4.00	6.69	1.44	5,200
G2911006X	5/8 x 6	0.62	1.25	2.50	0.62	3.00	6.00	8.69	1.44	5,200
G2911008X	5/8 x 8	0.62	1.25	2.50	0.62	3.00	6.00	8.69	1.44	5,200
