Herc

Single Wooden Yarding Block

Name: Single Wooden Yarding Block
Brand: Herc
SKU: hs213x
Price: 30.02 CAD
Availability: InStock

SKU: Part #hs213x

$30.02 CAD

Sale Low stock

Block Size 3" 4" 5" 6" 8"

Quantity

View full details

Product Description

Hercules 3 inch wood rope block—commonly known as a wooden pulley or a wood block. This block is a mechanical assembly traditionally used to lift heavy loads using manila or synthetic rope. It consists of a protective wooden outer frame (the shell), an internal grooved wheel (the sheave) with a hook with latch and becket other end

Material:
For use with fibre rope
Galvanized strap, sheave and hook
Design Factor: 4:1
Identification: Trademark, Size/WLL

Specifications:
Rope size 3/8” manila or synthetic rope
Design Factor: 4:1 • Identification: Trademark, Size/WLL
WLL 500 lbs

Uses:
Marine application
Roofing

Key Features:
When combined in a system, they provide a simple 2:1mechanical advantage
Shipping weight 1.2 lbs

Part Number	Block Size (in)	Working Load Limit (lb)
HS213X	3	500
HS214X	4	1,000
HS215X	5	1,200
HS216X	6	1,800
HS218X	8	2,800

*: Ultimate load is 4 times the Working Load Limit.

Specification	Value
Working Load Limit	500 LBS
Type	WOOD BLOCK
Size	3/8"
Sheave Size	3"
Rope Type	Fibre Rope
Rope Diameter	3/8"
Number of Sheaves	1
Max. Cable Size	3/8"
Material	Wooden with 45# Hook
Finish	Galvanized Hook
End Fitting Type	Hook
Configuration	Hook
Bearing Type	Brone Bush
