TROLLEY 1/2 TONNE MANUAL - KITO

Product Description

The Kito TSP Series Plain Trolley is a 0.5-ton (500 kg) rated manual push trolley designed for use with compatible Kito chain hoists and manual hoists on overhead beam systems. Compatible with beam flange widths of 2 to 4 inches, this trolley is suited for lighter structural beams and smaller overhead lifting installations commonly found in light industrial, workshop, and maintenance environments. The plain trolley configuration allows the hoist and load to be manually pushed or pulled along the beam, providing lateral load positioning capability without a motorized or geared drive system.

The TSP Series designation identifies this trolley within the Kito trolley product line, ensuring compatibility with the correct hoist mounting hardware and beam specifications for this series. The 0.5-ton working load limit is consistent with the capacity of the hoist it is intended to support, and the trolley and beam structure must both be rated for the combined weight of the trolley, hoist, and applied load before installation.

The Kito TSP Plain Trolley is well suited for light industrial facilities, workshops, and maintenance environments where manual lateral load positioning along smaller overhead beam sections is required.

Specifications: Series: TSP Working Load Limit: 0.5 Ton (500 kg) Beam Flange Range: 2 to 4 in Trolley Type: Plain (Manual Push)

Compatible With: Kito chain hoists and manual hoists compatible with TSP series trolley mounting Standard I-beam and wide-flange beams with 2 to 4 in flange width Overhead lifting systems rated for the applied load

Uses: Manual lateral load positioning along overhead beam systems Light industrial and workshop environments Maintenance and assembly shops with smaller beam infrastructure Paired use with compatible Kito chain hoists for complete overhead lifting and positioning systems

Key Features: 0.5-ton working load limit 2 to 4 in beam flange compatibility — suited for lighter structural beam profiles Plain trolley design for manual push/pull lateral positioning Kito TSP Series

Note: Verify hoist mounting compatibility and beam capacity with the manufacturer's documentation before installation. Never exceed the rated capacity of the trolley, hoist, or supporting beam structure.
