TROLLEY PLAIN 3 TON KITO / S-LUGS 3.25-6

Product Description

The Kito Plain Trolley is a 3-ton rated manual push trolley designed for use with S-lug mounted chain hoists and manual hoists on overhead beam systems. Compatible with beam flange widths of 3.25 to 6 inches, this trolley accommodates a wide range of standard I-beam and wide-flange beam profiles commonly used in industrial overhead lifting installations. The plain trolley configuration allows the hoist and load to be manually pushed or pulled along the beam, providing lateral load positioning capability without a motorized drive system.

S-lug mounting provides a secure, positive connection between the trolley and the hoist, ensuring the hoist remains properly aligned and retained during lifting and travel operations. The 3-ton working load limit is consistent with the capacity of the hoist it is intended to support, and the trolley and beam structure must both be rated for the combined weight of the trolley, hoist, and applied load before installation.

The Kito Plain Trolley is well suited for industrial facilities, maintenance shops, and construction environments where manual lateral load positioning along an overhead beam is required in conjunction with a compatible Kito chain hoist or manual hoist.

Specifications: Working Load Limit: 3 Ton Mounting Type: S-Lug Beam Flange Range: 3.25 to 6 in Trolley Type: Plain (Manual Push)

Compatible With: Kito chain hoists and manual hoists with S-lug mounting Standard I-beam and wide-flange beams with 3.25 to 6 in flange width Overhead lifting systems rated for the applied load

Uses: Manual lateral load positioning along overhead beam systems Industrial maintenance and assembly shops Construction and fabrication facilities with overhead beam infrastructure Paired use with compatible Kito chain hoists for complete overhead lifting and positioning systems

Key Features: 3-ton working load limit S-lug mount for secure hoist connection 3.25 to 6 in beam flange compatibility — accommodates a wide range of standard beam profiles Plain trolley design for manual push/pull lateral positioning Kito Series

Note: Verify beam capacity, trolley working load limit, and hoist compatibility with the manufacturer's documentation before installation. Never exceed the rated capacity of the trolley, hoist, or supporting beam structure.
