G-100 Swivel Self-Locking Hook with Ball Bearing

Name: G-100 Swivel Self-Locking Hook with Ball Bearing
Brand: Herc
SKU: x-027n-13x
Price: 329.5 CAD
Availability: InStock

SKU: Part #x-027n-13x

$329.50 CAD

Sale Low stock

Chain Size 1/2" 3/4" 5/8" 7/8"

Quantity

View full details

Product Description

Hook swivel self-locking hook with a ball bearing is a high-strength, Grade 100 forged alloy steel hook designed for overhead lifting. These hooks automatically lock under load and feature a swivel mechanism, allowing 360° rotation under load to prevent twisting of the load

Material:
- Alloy Steel, Grade 100
- Finish: Powder Coated, Blue

Specifications:
- Standard: EN 1677-3 / ASTM A952/952M
- Design Factor: 4:1
- Identification: Trademark, Size/WLL,

Uses:
- Precision Load Positioning
- Preventing Sling Twists

Key Features:
- Rotation: Ball bearing design allows for rotation while under load (full swivel).
- Safety: Self-locking mechanism automatically engages when loaded, remaining closed until released.
- Compliance: Meets EN 1677 and ASME B30.10/B30.26 standards.

Brass Bushing Part Number	Grade 100 Chain Size (in)	Working Load Limit (lb)	Dimension A (in)	Dimension B (in)	Dimension D (in)	Dimension H (in)	Dimension K (in)	Dimension P (in)	Dimension T (in)	Weight Each (lb)
X-027N-13	1/2	15,000	1.81	1.73	0.83	1.54	10.87	2.01	1.18	9.0
X-027N-16	5/8	22,600	2.40	2.19	0.91	2.00	12.95	2.36	1.42	15
X-027N-20	3/4	35,300	2.91	3.23	0.98	2.56	15.24	2.76	1.93	27.8
X-027N-22	7/8	42,700	3.82	3.74	1.30	2.80	17.99	3.15	2.09	39.6

Reference Image:

HERC Grade 100 brass bushing specification reference showing dimensions A, B, D, H, K, P and T

Specification	Value
Working Load Limit	6.7T, 6.7 Tons
Weight	9
Type	SWIVEL SELF LOCKING W/BEARING, Swivel Self-Locking w/ Bearing
Size	1/2, 1/2”
Material	Forged Super Alloy Steel, Alloy Steel
Certification Standard	EN1677 / ASME B30.26
