Yale Y80 Air Wire Rope Hoist - 2 Ton Double Reeving 14 ft Lift 16 FPM

Product Description

The Yale Y80 Air Wire Rope Hoist is a heavy-duty pneumatic lifting unit designed for industrial material handling, equipment positioning and overhead lifting applications. These double-reeved models are available with capacities of 1 Ton or 2 Ton. The 1 Ton models provide a 33 FPM lifting speed with either an 18 ft or 34 ft Lift, while the 2 Ton models provide a 16 FPM lifting speed with either a 14 ft or 25 ft Lift.

Double reeving routes the wire rope through the lower block to provide stable load handling and support the rated lifting capacity. The Y80 product family combines a compact wire-rope-and-drum arrangement with a heavy welded steel frame, powerful drive system and enclosed oil-bath-lubricated gearing. Dual braking provides reliable load control during lifting, lowering and holding operations.

The Y80 uses a deep-grooved, large-diameter rope drum to help guide the wire rope and reduce overlapping, while preformed plow-steel wire rope provides strength and service life. A swivelling, heat-treated forged lower hook with a spring-loaded latch supports secure load attachment, and the shrouded lower block helps reduce access to potential pinch points. The modular Y80 design is available in multiple suspension, trolley, lift and speed configurations for integration into suitable overhead lifting systems.

Material:
Heavy welded steel frame
Alloy aluminum gearcase and cover
Preformed plow-steel wire rope
Heat-treated forged steel lower hook
Steel rope drum
Metal lower hook block

Compatible With:
Properly rated overhead lifting structures
Yale Y80 lug-mounted configurations
Yale Y80 push trolley configurations
Yale Y80 hand-geared trolley configurations
Yale Y80 motorized trolley configurations
Compressed-air systems sized for the selected hoist model

Uses:
Industrial lifting and lowering
Manufacturing and production operations
Equipment installation and maintenance
Fabrication and assembly work
Warehouse material handling
Controlled positioning of suspended loads
Applications where pneumatic power is preferred
Overhead crane and monorail systems

Key Features:
Available in 1 Ton and 2 Ton capacities
Double-reeved wire rope configuration
18 ft Lift on the first 1 Ton model
34 ft Lift on the second 1 Ton model
14 ft Lift on the first 2 Ton model
25 ft Lift on the second 2 Ton model
33 FPM lifting speed on the 1 Ton models
16 FPM lifting speed on the 2 Ton models
Heavy welded steel frame
Compact modular construction
Enclosed oil-bath-lubricated drive train
Dual braking system
Deep-grooved large-diameter rope drum
Preformed plow-steel wire rope
Heat-treated forged lower hook
Spring-loaded hook latch
Full-swivelling lower hook
Shrouded lower block
Anti-friction drive-train bearings
Triple-reduction helical and spur gearing
Multiple suspension and trolley configurations available

Note:
The screenshot does not identify the suspension, trolley arrangement, control type, required air pressure or airflow for these specific models. Confirm the complete configuration and compressed-air requirements before publishing additional row-specific specifications.
