Coffing EC Series Electric Chain Hoist - 0.5 Ton Single Reeving Small Frame 15 ft Lift 9 FPM 230/460 VAC

Product Description

The Coffing EC Series Electric Chain Hoist is a high-performance lifting unit engineered for heavy-duty industrial service. The single-reeved small-frame configurations shown are available in 0.25 Ton, 0.5 Ton and 1 Ton capacities, with 10, 15 or 20 ft Lift options and one-speed lifting speeds ranging from 9 to 64 FPM. Electrical configurations include 115/230 VAC and 230/460 VAC models with 1/4, 1/2 or 1 hp motors.

Strong, lightweight aluminum alloy die-cast housings create a compact protective enclosure for the mechanical and electrical components. Heat-treated alloy steel gearing operates in an oil bath for dependable lubrication and effective heat dissipation. The EC Series includes an overload-limiting clutch, a mechanical load brake and an independent motor brake to support controlled lifting and secure load holding.

The listed small-frame models provide 16-7/8 in headroom and share an approximately 23-3/8 in L x 11-5/8 in W x 8 in H housing. Available operating weights range from approximately 100 to 118 lb, depending on motor size and lifting speed. Adjustable upper and lower limit switches restrict hook travel, while the white enamel finish provides a clean, durable exterior for production, assembly and maintenance environments.

Material:
Aluminum alloy die-cast housing
Heat-treated alloy steel gearing
White enamel exterior finish

Compatible With:
Properly rated overhead suspension points
Coffing hook or lug suspension configurations
Coffing plain, geared and motorized trolley configurations
115/230 VAC electrical service for applicable models
230/460 VAC electrical service for applicable models

Uses:
Heavy-duty industrial lifting
Manufacturing and production operations
Assembly and fabrication applications
Equipment installation and maintenance
Warehouse material handling
Controlled positioning of suspended loads

Key Features:
Single-reeved small-frame construction
Independent motor and mechanical load brakes
Overload-limiting clutch
Oil-bath-lubricated gearing
Adjustable upper and lower limit switches
Compact 16-7/8 in headroom
One-speed control
