Crosby S-2131 Trawling Shackles - 3.25 Ton - 5/8 in Size, 19.1 in Length

Description du produit

The Crosby S-2131 Western Trawling Shackle is a forged steel marine shackle engineered for the rigorous demands of commercial fishing, trawling operations, and heavy marine rigging. The 3.25 Ton working load limit and 5/8 in body size position this model as a reliable mid-range option for trawling gear assemblies, net rigging, wire rope terminal connections, and general marine load handling where a compact yet strong shackle profile is required. Built to Crosby's established standards for rigging hardware, the S-2131 series is a trusted choice across marine, offshore, and industrial applications worldwide.

The Western trawling bow profile provides a wider bearing surface than standard D or anchor shackles, accommodating the wire rope, chain, and synthetic rigging components commonly used in commercial fishing gear. The bolt-type pin with nut and cotter ensures the connection remains secure under the dynamic and cyclic loading conditions typical of trawling and marine lifting service. The red painted finish aids in visual identification on deck and provides a base level of surface protection, with the forged steel body and heat treated alloy steel pin delivering the core structural integrity required for sustained marine use.

Dimensional specifications for this model include a 2 in inner length, 1.06 in inner width, 1.06 in jaw opening, 1.56 in eye outer dimension, 3.78 in overall length, and 2-3/4 in overall width, with a 19.1 mm pin diameter. These dimensions ensure compatibility with standard trawling hardware and rigging components sized for the 5/8 in shackle class. The S-2131 5/8 in model is the smaller companion to the 3/4 in 4.75 Ton variant in the same series, offering the same construction quality in a more compact form factor suited to lighter gear configurations.

Material: Forged steel body Heat treated alloy steel bolt pin Red painted finish

Compatible With: Wire rope, chain, and synthetic slings rated to 3.25 Ton or greater Standard trawling gear, net rigging, and marine lifting assemblies Cotter pin retention system included with bolt pin configuration

Uses: Commercial fishing and trawling gear rigging Marine lifting and load securing Offshore and coastal rigging applications General industrial rigging where a wide-bow shackle profile is required Net and wire rope terminal connections in lighter gear configurations

Key Features: 3.25 Ton working load limit 5/8 in body size Forged steel body construction Heat treated alloy steel bolt pin Bolt pin with nut and cotter for secure retention Western trawling shackle bow profile 2 in inner length 1.06 in inner width 1.06 in jaw opening 1.56 in eye outer dimension 3.78 in overall length 2-3/4 in overall width 19.1 mm pin diameter Red painted finish Crosby S-2131 series
