Crosby SL-150 Metric Slide-Loc™ Lifting Point – Bolt Size M24 x 3 x 60

Description du produit

Product Description:
Crosby SL-150M Metric Slide-Loc® Lifting Points are designed to provide a quick, secure, and efficient lifting connection, ideal for applications requiring frequent installation and removal of lifting points.
Featuring a patented Slide-Loc® locking mechanism, these lifting points allow for tool-free installation, significantly reducing setup time while maintaining a secure connection. The lifting bail swivels 360°, ensuring proper alignment with the load and minimizing side loading during lifting operations.

Material:
Body: Alloy steel (quenched and tempered)
Bolt: Metric Grade 10.9 alloy cap screw (ISO 898-1)
Finish: Corrosion-resistant coating

Specifications:
Metric threaded design (M-series)
Available sizes: approx. M10 to M24 thread sizes
Working Load Limit range: approx. 0.5 ton to 3.2 ton (500 kg to 3,200 kg)
360° swivel bail for load alignment
Rated at 100% Working Load Limit at 90° angle
4:1 design factor (ultimate strength = 4× WLL)
Fatigue rated to 20,000 cycles at 1.5× WLL
Individually proof tested for safety
Equipped with QUIC-CHECK® visual indicator to confirm proper engagement before lifting
CE compliant (Machinery Directive 2006/42/EC)

Uses:
Machinery and equipment lifting
Tooling, dies, and mold handling
Applications requiring quick-change lifting points
Industrial environments with frequent rigging adjustments

Key Features:
Slide-Loc® system – Fast, tool-free installation and removal
360° swivel – Aligns automatically with load direction
QUIC-CHECK® indicator – Visual safety confirmation before lifting
Compact design – Ideal for tight or confined spaces
High strength – Forged alloy steel construction
Fatigue rated – Built for repeated lifting cycles
