Coffing WRMT Series Electric Wire Rope Hoist - 2 Ton Single Reeving Large Frame 22 ft Lift 14 FPM

Product Description

Product Description:
The Coffing WRMT Series Electric Wire Rope Hoist combines heavy-duty powered lifting with an integrated motorized trolley for horizontal load travel along a compatible overhead beam. These single-reeved large-frame models are available in 2 Ton, 3 Ton and 5 Ton capacities with lifting heights ranging from 20 to 44 ft.

The 2 Ton and 3 Ton configurations use 5/16 in wire rope and provide a 14 FPM lifting speed. The 5 Ton configuration uses 3/8 in wire rope and provides a 16 FPM lifting speed. One-speed control delivers consistent lifting and lowering, while the large-frame construction accommodates 2, 3 and 5 hp motors based on the selected capacity.

The motorized trolley reduces the manual effort required to move suspended loads between work areas. An AC disc-type braking system provides controlled stopping and dependable load holding, making the WRMT Series suitable for repetitive production lifting, equipment handling and other demanding industrial applications.

Material:
Steel wire rope
Metal hoist frame and housing
Machined metal rope drum
Steel motorized trolley components
Hardened steel drive components
Forged steel hook assemblies

Compatible With:
Properly rated overhead beams
Approved overhead supporting structures
Compatible beam-flange dimensions
Electrical service matching the selected model
Manufacturer-approved wire rope and replacement components

Uses:
Heavy-duty industrial lifting
Powered movement along overhead beams
Manufacturing and production operations
Assembly and fabrication applications
Equipment installation and maintenance
Warehouse material handling
Moving heavy loads between workstations

Key Features:
2 Ton to 5 Ton capacity options
Single-reeved wire-rope construction
Large-frame industrial design
Integrated motorized trolley
20, 22, 35 and 44 ft Lift options
14 and 16 FPM lifting speeds
2 to 5 hp motor configurations
One-speed control
AC disc-type braking system
