Western N-301B Series Manila Rope Steel Shell Block - 2,000 lb - 3/4 in Manila Rope - 6 in Sheave

Description du produit

Product Description: The Western N-301B Series 2000 lb Manila Rope Steel Shell Block is a compact and durable single-groove rigging block designed for use with manila rope cable up to 3/4 inch in diameter in general rigging, construction, marine, and industrial applications where a reliable and manageable block is required for light to medium duty rope-based lifting and pulling operations. Steel shell blocks offer the durability and strength of an all-steel construction in a compact form factor well suited to a wide range of field and shop rigging tasks. The N-301B Series in this configuration is rated to a 2000 lb working load limit and is well matched to light to medium duty rigging applications where manila rope is the preferred or specified line material and a single-groove block for 3/4 inch rope is required.

The single 3-1/2 inch sheave accommodates manila rope up to 3/4 inch in diameter and provides reliable rope guidance within the compact overall block dimensions. The sheave runs on a self-lubricating bronze bushing bearing, a proven and low-maintenance bearing solution well suited to field rigging environments where regular lubrication may not always be practical. Self-lubricating bronze bushings deliver consistent performance across a range of operating conditions, resist corrosion, and provide reliable service life in both indoor and outdoor applications without requiring frequent maintenance intervention. The 6 inch block size provides a practical and manageable form factor suited to rigging configurations where a compact block for 3/4 inch manila rope is preferred.

The N-301B Series steel shell block in this 3/4 inch rope configuration is designed for integration into general rigging, block and tackle, and rope-based lifting and pulling systems where a dependable light to medium capacity single-groove manila rope block in a compact steel shell configuration is required. The block is compatible with standard rigging hardware including hooks and shackles rated to the appropriate working load limit. All connected rigging components must be rated to 2000 lb or greater, and the block must be inspected before each use in accordance with applicable lifting and rigging safety standards. Manila rope must be inspected for wear, fraying, and degradation before each use and replaced when signs of deterioration are present.

Material: Steel shell block body Steel sheave Self-lubricating bronze bushing bearing

Compatible With: Manila rope cable up to 3/4 in diameter Hooks, shackles, and rigging hardware rated to 2000 lb or greater General rigging and block and tackle systems configured for 3/4 in manila rope

Uses: General construction site lifting and rigging operations Block and tackle lifting and pulling assemblies Marine and boat rigging applications Industrial and shop rigging tasks Light to medium duty field rigging requiring a compact single-groove steel shell block for 3/4 in manila rope

Key Features: 2000 lb working load limit N-301B Series designation Single groove - 3-1/2 in sheave outside diameter 6 in block size for a compact and manageable form factor suited to 3/4 in manila rope Accommodates manila rope cable up to 3/4 in diameter Self-lubricating bronze bushing bearing for low-maintenance reliable performance Durable all-steel shell construction

Note: All connected rigging hardware must be rated to the working load limit of this block. Inspect the block, sheave, bearing, and all attachment points before each use. Inspect manila rope for wear, fraying, and deterioration before each use and replace when necessary. Follow applicable lifting and rigging safety standards and do not exceed the rated working load limit.
