Manual Plain Push Trolley - 1/4 to 1/2 Ton, 2-5/8 to 4-5/8 in Beam Flange

Product Description

CM manual plain push trolleys provide manually controlled horizontal travel for compatible hoists mounted on overhead beams. The listed configurations cover capacities from 1/4 to 3 Ton with model-specific beam flange and beam height requirements. The 3 Ton trolley fits 9 to 11 in beam flanges and a 6 in beam height, while the 1 Ton trolley fits 3 to 5 in beam flanges and a 5 in beam height.

The lower-capacity configurations include a 1/2 to 3/4 Ton trolley for 3 to 5 in beam flanges and a 5 in beam height, along with a 1/4 to 1/2 Ton trolley for 2-5/8 to 4-5/8 in beam flanges and a 4 in beam height. Each trolley must be matched to the rated capacity, suspension arrangement, and dimensions of the hoist and supporting beam.

Horizontal movement is produced by manually pushing or pulling the suspended load. This straightforward design eliminates the need for a trolley motor, electrical controls, or a hand-chain gear drive. These trolleys are suitable for maintenance, fabrication, assembly, equipment installation, and general material-handling applications where powered beam travel is unnecessary.

Material:
Industrial metal trolley frame
Metal trolley wheel assemblies
Steel suspension and mounting components
Manufacturer-specific beam adjustment hardware

Compatible With:
Compatible CM hoists with the correct suspension arrangement
Properly rated overhead beams within the specified flange-width range
Supporting beams matching the specified beam height
Compatible manual, electric, or pneumatic hoists within the trolley’s rated capacity

Uses:
Providing manual horizontal travel for suspended hoists
Positioning loads along overhead beams
Industrial maintenance and equipment installation
Fabrication and assembly operations
Production and material-handling applications
Applications where powered trolley travel is unnecessary

Key Features:
Manual push-type operation
Available in capacities from 1/4 to 3 Ton
No electrical or pneumatic trolley power required
No separate hand-chain gear drive
Model-specific beam flange compatibility
Capacity-specific hoist mounting arrangements
Simple and controlled horizontal load positioning
Suitable for industrial overhead lifting systems
