Western N-413B Series Synthetic Fiber Rope Steel Block - 6,000 lb - 3/4 in Synthetic Fiber Rope

Description du produit

Product Description: The Western N-413B Series 6000 lb Synthetic Fiber Rope Steel Block is a compact and durable triple-groove rigging block designed for use with synthetic fiber rope cable up to 3/4 inch in diameter in general rigging, construction, marine, and industrial applications where maximum mechanical advantage and multi-part line reeving are required in a manageable block. Standard steel blocks offer the durability and strength of an all-steel construction in a compact form factor well suited to a wide range of field and shop rigging tasks. The N-413B Series is rated to a 6000 lb working load limit and is well matched to medium duty rigging applications where synthetic fiber rope is the preferred or specified line material and a triple-groove configuration is required for compound block and tackle arrangements with 3/4 inch rope.

The three 3-1/2 inch sheave grooves allow this block to be used in multi-part line reeving arrangements with up to three rope parts running through the block simultaneously, enabling significant mechanical advantage and increased effective lifting capacity when configured in a compound block and tackle system. The sheaves run on self-lubricating bronze bushing bearings, a proven and low-maintenance bearing solution well suited to field rigging environments where regular lubrication may not always be practical. Self-lubricating bronze bushings deliver consistent performance across a range of operating conditions, resist corrosion, and provide reliable service life in both indoor and outdoor applications without requiring frequent maintenance intervention. The 6 inch block size accommodates the 3/4 inch rope diameter and three 3-1/2 inch sheaves in a compact and manageable steel block form factor suited to a wide range of rigging configurations, and the 6000 lb working load limit reflects the substantial capacity enabled by the triple-groove reeving arrangement.

The N-413B Series standard steel block in this 3/4 inch rope configuration is designed for integration into compound block and tackle systems and rope-based lifting and pulling arrangements where a dependable medium-capacity triple-groove synthetic fiber rope block in a compact steel construction is required. The block is compatible with standard rigging hardware including hooks and shackles rated to the appropriate working load limit. All connected rigging components must be rated to 6000 lb or greater, and the block must be inspected before each use in accordance with applicable lifting and rigging safety standards. Synthetic fiber rope must be inspected for wear, abrasion, and degradation before each use and replaced when signs of deterioration are present.

Material: Steel block body - Standard configuration Steel sheaves Self-lubricating bronze bushing bearings

Compatible With: Synthetic fiber rope cable up to 3/4 in diameter Hooks, shackles, and rigging hardware rated to 6000 lb or greater General rigging and compound block and tackle systems configured for 3/4 in synthetic fiber rope and triple-groove reeving

Uses: General construction site lifting and rigging operations Multi-part line and compound block and tackle lifting and pulling assemblies Marine and boat rigging applications Industrial and shop rigging tasks Medium duty field rigging requiring maximum mechanical advantage in a compact triple-groove standard steel block for 3/4 in synthetic fiber rope

Key Features: 6000 lb working load limit N-413B Series designation Standard steel block configuration Triple groove - 3-1/2 in sheave outside diameter 6 in block size for a compact and manageable form factor suited to 3/4 in synthetic fiber rope Enables multi-part line reeving for significant mechanical advantage in compound lifting systems Accommodates synthetic fiber rope cable up to 3/4 in diameter Self-lubricating bronze bushing bearings for low-maintenance reliable performance Durable all-steel construction

Note: All connected rigging hardware must be rated to the working load limit of this block. Inspect the block, sheaves, bearings, and all attachment points before each use. Inspect synthetic fiber rope for wear, abrasion, UV degradation, and chemical exposure before each use and replace when necessary. Follow applicable lifting and rigging safety standards and do not exceed the rated working load limit.
