Budgit Heavy-Duty Push Rigid-Mount Trolley - 5/6 Ton, 4 to 6-1/4 in Beam Flange, Spark Resistant

Product Description

Budgit heavy-duty push rigid-mount spark-resistant trolleys provide manually controlled horizontal travel for compatible hoists and suspended loads on overhead runway beams. The listed configurations include 3/4, 5/6, 1, and 2 Ton capacities with model-specific beam-flange ranges. Their heavy-duty construction is intended for demanding industrial lifting systems where powered or hand-geared trolley travel is unnecessary.

The rigid-mount suspension connects a compatible hoist directly to the trolley assembly rather than using an intermediate suspension hook. This compact arrangement helps conserve available lifting height and provides a stable hoist-to-trolley connection for production, maintenance, fabrication, processing, and equipment-installation applications. Each trolley must be matched to the hoist capacity, rigid mounting interface, runway dimensions, and required wheel clearances.

Horizontal movement is produced by manually pushing or pulling the suspended hoist and load. The 1 Ton model fits beam flanges from 3 to 5 in, the 2 Ton model fits flanges from 3-5/8 to 6 in, and the 3/4 and 5/6 Ton models fit flanges from 4 to 6-1/4 in. Designated spark-resistant components help reduce the potential for mechanically generated sparks during trolley travel.

Material:
Industrial metal trolley side frames
Rigid-mount suspension components
Trolley wheel and axle assemblies
Metal beam-adjustment hardware
Manufacturer-selected spark-resistant components

Compatible With:
Compatible Budgit hoists using the required rigid-mount suspension
Overhead beams within the selected trolley’s flange-width range
Capacity-matched hoist and trolley mounting components
Runway beams providing the required wheel and flange clearances
Complete lifting systems approved for the intended operating environment

Uses:
Providing manual horizontal travel for suspended hoists
Positioning loads along overhead runway beams
Low-headroom lifting installations
Industrial maintenance and equipment installation
Fabrication and assembly operations
Processing and manufacturing applications
Material handling where reduced-sparking construction is required

Key Features:
Heavy-duty push-type operation
Rigid-mount suspension configuration
Spark-resistant construction
Available in 3/4, 5/6, 1, and 2 Ton capacities
Model-specific beam-flange compatibility
Compact mounting for improved available headroom
No electric or pneumatic trolley motor required
No separate trolley hand-chain drive
Controlled horizontal movement along compatible runway beams
