Budgit Manual Plain Push Trolley - 1 Ton, Rigid Suspension, 3 to 5 in Beam Flange

Description du produit

Budgit rigid-suspension manual plain push trolleys provide horizontal beam travel for compatible hoists and suspended loads. The listed configurations cover 1/2, 1, 2, and 3 Ton capacities with multiple beam-flange adjustment ranges. Their manual operating design is suitable for maintenance, fabrication, assembly, production, and general industrial material-handling applications where powered or hand-geared trolley travel is unnecessary.

The rigid-suspension arrangement connects the compatible hoist directly to the trolley assembly instead of using an intermediate suspension hook. This creates a compact hoist-and-trolley installation and can help preserve available lifting height in areas with limited overhead clearance. Each trolley must be matched to the hoist capacity, rigid mounting arrangement, beam flange dimensions, and required wheel clearance.

Horizontal movement is produced by manually pushing or pulling the suspended hoist and load along the runway beam. The 1/2 Ton configuration fits beam flanges from 2-5/8 to 4-5/8 in. The 1 Ton configurations fit flange ranges from 3 to 5 in, 5-1/4 to 7-3/8 in, or 7-1/2 to 9 in. The 2 Ton models fit 3-3/8 to 6 in or 6-1/4 to 8-7/8 in flanges, while the 3 Ton models fit 3-3/8 to 6 in, 6-1/8 to 8-7/8 in, or 9 to 11 in flanges.

Material:
Industrial metal trolley side frames
Metal trolley wheel assemblies
Rigid-suspension mounting components
Metal beam-adjustment and fastening hardware
Exact manufacturer material grades not confirmed

Compatible With:
Compatible Budgit hoists using the required rigid-suspension connection
Overhead beams within the selected trolley’s flange-width range
Capacity-matched hoist and trolley mounting components
Runway beams providing the required wheel and flange clearances

Uses:
Providing manual horizontal travel for suspended hoists
Positioning loads along overhead runway beams
Low-headroom lifting installations
Industrial maintenance and equipment installation
Fabrication and assembly operations
Production and manufacturing applications
Warehouse and general material handling

Key Features:
Manual push-type trolley travel
Rigid-suspension configuration
Available in 1/2, 1, 2, and 3 Ton capacities
Multiple beam-flange adjustment ranges
Compact direct hoist mounting
No electric or pneumatic trolley motor required
No separate trolley hand-chain drive
Suitable for controlled short-distance load positioning
Designed for compatible industrial overhead lifting systems
