Budgit Series 6000 Air Chain Hoist - 3 Ton Hook Suspension 10 ft Lift

Product Description

The Budgit Series 6000 Air Chain Hoist is designed for pneumatic lifting and controlled load handling in industrial environments. These standard 3 Ton models feature triple reeving and a 10 ft lifting height. The available configurations include hook or lug suspension with either a 4 FPM slow lifting speed or a 10 FPM fast lifting speed, allowing the hoist configuration to be matched to the required balance of positioning control and material-handling speed.

A multi-vane rotary air motor provides high starting torque, smooth acceleration and responsive control. The pendant throttle control allows the operator to vary the lifting and lowering speed through the position of the control lever, supporting accurate load spotting. The Series 6000 also incorporates an internal muffler, a mechanical load brake, heat-treated gearing, upper and lower travel-limit stops and overload protection to support dependable operation.

Hook-suspension models provide a portable mounting arrangement that allows the hoist to be moved between suitable supporting locations and have a 24-7/8 in minimum distance between hooks. Lug-suspension models provide a rigid mounting connection for attachment to a suitable overhead structure or compatible Budgit rigid-mount trolley. The recommended operating pressure is 90 PSI, with approximately 70 SCFM required by slow-speed models and 80 SCFM by fast-speed models at full rated load and full speed.

Material:
Die-cast aluminum frame
Aluminum alloy gearcase cover
Precision-cut, heat-treated alloy steel helical and spur gears
Carburized steel coil load chain
Industrial-duty steel hook or suspension lug

Compatible With:
Suitable overhead supports rated for the combined hoist and load weight
Budgit rigid-mount trolleys when equipped with lug suspension
Compressed-air systems capable of providing 90 PSI
3/4 NPTF air inlet connections
Air-supply hoses with a minimum 3/4 in inside diameter

Uses:
Industrial lifting and material handling
Manufacturing and production operations
Assembly-line load positioning
Equipment maintenance and repair
Warehouse and service-shop lifting
Applications requiring pneumatic rather than electric operation
Controlled movement of loads up to 3 Ton

Key Features:
3 Ton rated lifting capacity
10 ft Lift
Standard triple-reeved load-chain configuration
Available with 4 FPM or 10 FPM lifting speed
Hook or lug suspension options
Pendant throttle control
Variable lifting and lowering speed
Eight-vane rotary air motor
Mechanical load brake
MAN-GUARD overload protection
Upper and lower travel-limit stops
Internal muffler for reduced operating noise
Smooth starting and accurate load positioning
Recommended operating pressure of 90 PSI
Approximately 70 SCFM for slow-speed models
Approximately 80 SCFM for fast-speed models
24-7/8 in minimum between hooks on hook-suspension models

Note:
This hoist is intended for lifting materials and is not designed or approved for lifting or lowering people. Confirm the supporting structure, suspension hardware, air pressure and airflow are suitable for the selected model before operation. Follow the manufacturer’s installation, inspection, lubrication and maintenance instructions.
