Budgit Series 6000 Spark-Resistant Air Chain Hoist - 2 Ton Hook Suspension 10 ft Lift

Product Description

The Budgit Series 6000 Spark-Resistant Air Chain Hoist is designed for controlled industrial lifting in environments where reducing the risk of mechanical sparking is important. These models have a 2 Ton load rating, triple-reeved load-chain configuration, 10 ft lifting height and 5 FPM lifting speed. Both configurations operate at 90 PSI and use pendant throttle control for convenient lifting and lowering from the operator’s working position.

The pneumatic motor provides infinitely variable speed control for smooth starts and accurate load positioning. Series 6000 hoists are designed for continuous-duty operation and incorporate an internal muffler to reduce operating noise, a throttle valve for smooth movement and overload protection to help guard the hoist against excessive loading. The screenshot identifies an airflow requirement of approximately 70 SCFM for these slow-speed configurations.

These products are available with either hook or lug suspension. The hook-suspension model provides a removable connection to a suitable overhead support and has a minimum distance of 24-7/8 in between hooks. The lug-suspension model provides a rigid mounting connection for integration with a suitable supporting structure or compatible trolley. Budgit states that its spark-resistant Series 6000 models use stainless steel load chain, operate at reduced speeds and are intended for medium-duty service because stainless steel chain has a lower wear life than standard load chain.

Material:
Stainless steel load chain
Industrial-duty metal hoist housing
Metal hook or mounting lug
Industrial-duty internal gearing

Compatible With:
Suitable overhead supporting structures
Compatible trolley arrangements when equipped with lug suspension
Compressed-air systems capable of supplying 90 PSI
Air systems capable of supplying approximately 70 SCFM
Spark-resistant stainless steel chain containers recommended for 10 ft Lift models

Uses:
Industrial lifting and material handling
Controlled positioning of suspended loads
Manufacturing and production operations
Maintenance and repair facilities
Applications where pneumatic power is preferred
Environments requiring spark-resistant lifting equipment
Medium-duty lifting applications

Key Features:
2 Ton rated load
10 ft Lift
5 FPM lifting speed
Spark-resistant configuration
Triple-reeved load chain
Hook or lug suspension
Pendant throttle control
Infinitely variable speed control
Smooth starting and accurate load spotting
Continuous-duty pneumatic motor
Internal muffler for reduced operating noise
Throttle valve for controlled operation
Built-in overload protection
90 PSI operating pressure
Approximately 70 SCFM air consumption
24-7/8 in minimum between hooks on the hook-suspension model
Stainless steel load chain
Reduced-speed configuration for spark-resistant service

Note:
Spark-resistant construction reduces potential mechanical sparking but does not make the hoist ignition-proof or automatically suitable for every hazardous location. Confirm the complete hoist, suspension, trolley and air-system configuration for the intended environment before installation. Budgit recommends a stainless steel spark-resistant chain container for spark-resistant models with a 10 ft lift.
