Yale YJL Electric Chain Hoist - 0.25 Ton Single Reeving Motorized Trolley 32 FPM

Product Description

The Yale YJL Electric Chain Hoist is a compact industrial-duty lifting unit designed for quick, precise load handling. The single-reeved configurations shown range from 500 lb to 2000 lb capacities, with lifting speeds of 8, 16 or 32 FPM. The group includes less-chain hoists with one-speed control and 115/230 or 230/460 VAC power, along with geared, motorized and universal motorized trolley configurations.

Tough, lightweight die-cast aluminum alloy housings protect the internal components without creating unnecessary weight. The oil-bath transmission uses heat-treated alloy steel gears for smooth, reliable operation, while the overload-limiting clutch helps prevent the hoist from lifting damaging overloads. Dual-voltage models use terminal-block connections that allow the hoist to be configured for the applicable supply voltage.

A magnetic multiple-disc motor brake provides positive stopping and secure load holding. Adjustable upper and lower limit switches regulate load travel, while safety-latch hooks and a slack-end chain stop support dependable operation. Trolley-mounted versions are available with geared or powered travel, and compatible trolley wheels are designed to operate on flat or tapered beam flanges.

Material:
Die-cast aluminum alloy hoist housing
Heat-treated alloy steel gears
Steel load chain on chain-equipped models
Forged steel hooks with safety latches
Steel trolley components on trolley-mounted models

Compatible With:
Properly rated overhead supporting structures
American Standard I-beams
Wide-flange beams
115/230 VAC electrical service for applicable models
230/460 VAC electrical service for applicable models
Manufacturer-approved Yale YJL load chain
Geared and motorized Yale trolley configurations

Uses:
Industrial production lifting
Manufacturing and assembly operations
Equipment installation and maintenance
Warehouse material handling
Movement of suspended loads along overhead beams
Workstation load positioning
Repetitive lifting and lowering applications

Key Features:
Compact single-reeved construction
Magnetic multiple-disc motor brake
Overload-limiting clutch
Oil-bath-lubricated alloy steel gearing
Adjustable upper and lower limit switches
Geared and motorized trolley options
One-speed lifting configurations
Dual-voltage options on applicable models
